Tube holders and float mounts for Zodiac RIB boats

Zodiac RIB boats are equipped with a patented, removable float system. This system allows the float (tube) to be completely removed and replaced when it becomes worn, damaged, or outdated. The main connection between the float and the fiberglass hull is thetendon connection, also called the slide-in string. In larger Zodiac RIBs, this connection is reinforced by a second attachment point: thetube holderat the back.

How does the Zodiac tube attachment work?

In almost all Zodiac RIBs, the tube is pulled into the rail (opening) of the polyester hull by a strong tendon. This ensures:

  • a secure, stable connection
  • a tight fit
  • easy maintenance and replacement

Larger models (such as PRO, PRO OPEN, MEDLINE and Yachtline) have an additional attachment at the rear: thetube holder / supportThis is placed in a recess on the top of the hull and keeps the tube perfectly in place, even in rough conditions.

Common problems and causes

A damaged or torn tube holder mainly occurs when:

  • the tube withinsufficient air pressureis used
  • the boat is heavily loaded
  • parts are outdated
  • the mounting is no longer mounted correctly

Sailing with a tube that is too soft puts extra stress on the attachment points, which can cause damage.

The importance of a properly fitted tube holder

For maximum safety and a longer lifespan of your Zodiac RIB it is essential that:

  • the float is always at the correct pressure
  • the tube holder sits firmly and completely in the recess
  • you replace a damaged fastener in time
  • you choose the right material (PVC or Hypalon)

Correct installation prevents tearing and significantly extends the life of both the tube and the hull.

PVC or Hypalon? Choose the right fastening

Zodiac uses two types of materials for floats:

  • PVCmaterial
  • Neoprene Hypalonmaterial (resistant to higher temperatures, chemical loads and intensive use)

It is important that the tube holder is always made of the same material as the float.

Not sure what material your Zodiac RIB is made of? We're happy to help.

Need advice on the correct mounting?

Please feel free to send us an email via thecontact formwith themodel, year of manufacture and serial numberof your Zodiac RIB. As an official specialist, we always supply the correct tube holder and help you with installation advice.
